BOSCH PLE-1MP30-IN – Mixer Amplifier Portable 30W
The Bosch PLE-1MP30-IN Portable 30W Mixer Amplifier is a powerful, easy-to-use PA solution featuring Bluetooth, USB, FM, TF card playback, dual mic inputs, ducking, and 12/24V battery support. Designed for on-the-go public address needs and small to medium installations.
₹13,299.00 Excluding Tax
Get Latest Price
Enquiry Now
BOSCH PLE-1MP30-IN – Mixer Amplifier Portable 30W
The BOSCH PLE-1MP30-IN – Mixer Amplifier Portable 30W is a powerful and fully portable public address solution designed for users who require mobility, simplicity, and professional audio performance. Built on a high-efficiency Class-D platform, it delivers excellent speech clarity and clean music reproduction, making it perfect for mobile announcements and compact commercial installations.
This versatile amplifier features an inbuilt music player that supports Bluetooth streaming, USB, TF card playback, and FM radio, offering multiple sources for uninterrupted audio. A supplied IR remote control enhances ease of operation.
Ideal for use in outdoor events, retail spaces, classrooms, yoga centers, gyms, political rallies, promotions, cafés, and more, the PLE-1MP30-IN delivers reliable performance with advanced protection and smart features.
🔹BOSCH PLE-1MP30-IN – Mixer Amplifier Portable 30W Smart Input & Playback Options
The portable amplifier includes:
-
Bluetooth audio streaming
-
USB and TF card playback
-
Built-in FM tuner
-
Two microphone inputs (Mic 2 with phantom power)
-
AUX input for external devices
This makes it a complete audio hub for both speech and music applications.
🔹BOSCH PLE-1MP30-IN – Mixer Amplifier Portable 30W Advanced Ducking & Audio Control
The adjustable ducking feature automatically lowers background music when speaking into a microphone. Ducking levels include:
-
0 dB, –6 dB, –24 dB, MUTE
This ensures clear, professional announcements without manual control.
🔹BOSCH PLE-1MP30-IN – Mixer Amplifier Portable 30W Battery & Protection Features
Designed for mobility, the amplifier supports:
-
12/24V battery operation
-
Battery level monitoring
-
Automatic low-battery shutdown protection
-
Short-circuit and overload protection
-
Replaceable rear DC fuse
These features safeguard both the amplifier and the battery system during use.
🔹 Reliable Class-D Efficiency
The Class-D amplifier design ensures:
-
Low power consumption
-
Lower heat dissipation
-
High output efficiency
-
Long operational life
All while delivering crisp, clean sound.
Key Features
-
30W Class-D portable mixer amplifier
-
Bluetooth, USB, FM, and TF card audio playback
-
Two mic inputs (Mic 2 with phantom power)
-
AUX input for external audio sources
-
Adjustable ducking levels
-
Supports 12/24V battery operation
-
Battery low indication & self-protection mode
-
Short-circuit and overload protection
-
Lightweight and ideal for mobile PA use
-
Includes IR remote control
Ideal Applications
-
Retail shops
-
Small cafés & restaurants
-
Yoga studios & fitness centers
-
Election rallies & promotional events
-
Classrooms & training centers
-
Outdoor gatherings
-
Mobile announcements
-
Small and medium public address installations
| Brand |
|---|
Technical specifications
Electrical
Power supply
Adapter 19 V ± 5%, ≥ 65 W output, 230 V /
50 Hz input
12 V ± 5%, ≥ 35 Ah
24 V ± 5% ≥ 35 Ah
Performance
Frequency response 20 Hz to 20 kHz (+1/-3 dB @ -10 dB of rated output)
Distortion <1% @ rated output power Ducking range 0 dB, -6 dB to -24 dB (+1 dB/-3 dB), Mute AUX input Connector 3.2 mm RCA mono jack Input impedance > 10 kΩ
Sensitivity 200 mV +1 dB / -3 dB
S/N > 70 dB
Headroom > 25 dB
Mic Input 1
Connector 1/4″ TRS stereo jack
Input impedance > 1 kΩ
Sensitivity 1 mV +1 dB / -3 dB
CMRR > 50 dB
S/N > 60 dB
Headroom > 25 dB
Mic Input 2
Connector 1/4″ XLR combo connector
Input impedance > 1 kΩ
Sensitivity 1 mV +1 dB / -3 dB
CMRR > 50 dB
S/N > 60 dB
Headroom > 25 dB
Phantom power supply 15 V ±10% – open circuit voltage
9 V ±10% – with 2.2 kΩ load resistor
Loudspeaker output
Connector 2 pin
Max. power 30 W for 19/24V
30 W (-1 dB) for 12V
Load resistance 4 Ohm
Output type Balanced
Line output
Connector XLR type
Max. output voltage 1 V for 19/24V
0.89 V for 12V
Output type Balanced
Indications on power button
Power on LED ON (green color ring around the power button)
Fault* LED blinking (red color ring around the power button)
5-second retry interval
Other indications
Battery source+ LED ON (yellow color)
Low battery** When the battery is low, the speaker and line outputs will be reduced by
3 dB and the LED starts blinking (red color) when it reaches threshold-1. The LED will be continuously ON when it reaches threshold-2 and the outputs will be muted.
Threshold details for battery of 12 V: Threshold 1 = 10.8 V ±2%, Recovery voltage = 11.4 V
Threshold 2 = 10 V ±2%, Recovery voltage = 10.6 V
Threshold details for battery of 24 V: Threshold 1 = 21.6 V ±2%, Recovery voltage = 22.8 V
Threshold 2 = 20 V ±2%, Recovery voltage = 21.2 V
